| product model | Area | Dimensions (unit: m) | ||
| Fold | 14.1m² | L | W | H |
| 5.8 | 2.44 | 2.53 | ||
| Quoter: | email: | |||
| Phone: | 86 | date: | 2024.10.25 | |
| Configuration type | Allocation division | Configuration item | Configuration description | Note | |||
| Standard configuration | Main framework | Top frame | 2.3mm galvanized formed crossbeam, with a galvanizing content of 80g/㎡ | ||||
| Galvanized C-shaped steel 80 * 1.2mm, galvanized content 80g/㎡ | |||||||
| 30 * 30 * 1.0mm galvanized square tube, with a galvanizing content of 80g/㎡ | |||||||
| Bottom frame | 2.3mm galvanized formed crossbeam, with a galvanizing content of 80g/㎡ | ||||||
| 50* 100* 1.2mm galvanized square tube, with a galvanizing content of 80g/㎡ | |||||||
| Pillar | 2.3mm galvanized column, with a galvanizing content of 80g/㎡ | ||||||
| Connection piece 2.0mm, galvanized content 80g/㎡ | |||||||
| lifting sling | 7mm angle steel, galvanized content 80g/㎡ | ||||||
| Paint | Lacquer baking (electrostatic spraying) |
||||||
| Bolt | Hexagonal socket bolt (galvanized) | ||||||
| Roof | Color-coated steel tile | 0.4mm colored aluminum single tile, 360-degree interlocking, special waterproof method | |||||
| Ceiling insulation | Moisture-proof | Moisture-proof film, PE resin film 1.0mm | |||||
| Glass wool | 75mm thick glass wool insulation cotton 14kg/m³ | ||||||
| Ceiling | Color steel plate | 0.3mm thick, 831 color steel ceiling panel | |||||
| Ground base layer | Cement fiberboard | 18mm | |||||
| Ground surface layer | Floor leather | 1.6mm，Floor leather | |||||
| Door | Medium-grade steel door | 925mm*1970mm | |||||
| Window | Single glass plastic steel window | 925mm*1130mm | |||||
| Electrical | Standard configuration | Industrial socket box+industrial socket 32A (1 set) distribution box J-8 (1), leakage protection (32A) air switch 32A (1), 1 three hole socket, 2 five hole sockets, 1 switch, 2 strip lamp. Main line 4mm ², air conditioning cable 4mm ², socket cable 2.54mm ², light cable 1.54mm ² | |||||
| Wall | 50mm rock wool composite board, double-sided steel sheet 0.3/0.3mm with orange peel texture on both sides, density 70kg/m³, with film coating. | 0.25mm thick substrate | |||||
| Describe | This price is only the factory price, excluding taxes and shipping costs. | ||||||
